14702029
FB1349
New product
Mellor FB1349 gear motor.
Speed: 2 rpm
Magnetic core: 32 mm
Shaft diameter: 9.52 mm
Shaft Milling: single
Rotation: clockwise
Output torque: 38 Nm
With encoder
14702029
Mellor FB1349 gear motor.
Speed: 2 rpm
Magnetic core: 32 mm
Shaft diameter: 9.52 mm
Shaft Milling: single
Rotation: clockwise
Output torque: 38 Nm
With encoder
More info
Designed for low speed and high torque applications. FB1349 geared motor is suited to be used as rotor in pellet stoves.
T3 series with encoder, 38 Nm output torque, 28 Watt consumption, 2 rpm speed, clockwise rotation, 9.52 mm shaft diameter, 32 mm magnetic core, 220 V AC 50/60 Hz power supply.
